Power Transmission Products S603RS Stainless Steel Bearing 3x9x3mm ABEC-1 316L S603-2RS Deep Groove Ball Bearings S603 RS

BearingsWHY 316L STAINLESS steel?316L stainless bearings which provides superior corrosion resistance when compared to conventional 440 stainless bearings. Type 316 stainless is widely used in the food medical marine industries. Bearings produced from this type of steel can run in liquids or can run dry at slow speeds.What is 316L?316/316L are austenitic stainless steels that contain molybdenum which increases their resistance to many chemical corrodents and marine environments. RINGS: AISI 316 stainless non-magnetic unground semi-precision.BALLS: Standard balls are 316 stainless. BALL RETAINER (CAGE): Standard ball retainers are Polypropylene or Acetal. When higher heat capability is required bearings can be manufactured with either a high temperature polymer cage or without a cage.SHIELDS/SEALS: Open design is standard. Polymer shields and seals can be provided on a special order basis.LUBRICATION: supplies the bearings with a light proprietary oil that reduces friction and noise and is non contaminating in most applications. TEMPERATURE FOR STANDARD MATERIALS:Acetal Cage: -40°F to 180°FPolypropylene Cage: -40°F to 140°F

• Bearings
• Item: S603RS; Structure: Deep Groove; Material: 316L Stainless Steel ( prefix "S" )
• Bore Dia (d): 3 mm; Outer Dia (D): 9 mm; Width (B): 3 mm
• Closures: Sealed (2RS); Lubrication: Grease (PE); Magnetic: little
• Corrosion Resistance: General; Clearance: C0
• Grades: ABEC Grades 1; Weight: 1.43 g; Quantity: 1 Lot = 1 PC
